Adopts Rockchip hardware platform and Android operating system
Quad-core Cortex A9, clocked at 1.4G Hz
Embedded installation, split screen design: screen + host
Includes RS232, USB and other communication interfaces for easy expansion
Support video input from 2 cameras
Support positioning
Support navigation
Support extended connection 360 monitoring
This product focuses on strengthening entertainment functions, including movies, music, Bluetooth music, dual-screen abnormal display, mobile phone screen projection, etc., vehicle control and safety functions, including camera functions (360 panoramic view, reversing), air conditioning setting functions, etc.
This product is suitable for “truck” models to meet the needs of truck drivers.Therefore, the aspects of “GPS positioning, path planning, reversing images, driver behavior norms, and fuel consumption” have been optimized.
Main parameter | Operating system | Android 7.1 |
| CPU | Quad-Cortex-A9@1.4GHz | |
| DDR | 1G | |
| EMMC | 16G | |
| Display | Screen size | 10.25'',horizontal screen |
| Resolution | 1920*720 | |
| Touch screen | Capacitive multi-touch screen | |
| Operating environment | Working temperature | -30℃ ~ +70℃ |
| Storage temperature | -40℃ ~ +85℃ | |
| Interface | RS-232 | 2x |
| Video input | 2x，supports up to 1080P/720 AHD, compatible with CVBS | |
| USB | 1x | |
| Function | Positioning | Support，GPS+BD |
| BT | Support | |
| WiFi | Support | |
| CAN | 2x CAN | |
| Video surveillance | 2x CVBS | |
| Truck navigation | Support | |
| Extended function | Connect to the multi-function steering wheel | Support |
| Connect the horn | Support, 2x power amplifier, support connection of 4 speakers | |
| Power | Working voltage | 10.8~32V |
| Structure | Weight (Host + screen) | 3kg |
| Screen size | 427.5mm×255.1mm×72mm | |
| Host size | 190mm×150mm×60mm |
